12W Wall-Mounted Power Adapter
Compact 12W wall-mounted power adapter series with multiple output options, AC plug types, and DC connector choices for consumer electronics and OEM/ODM projects.
Samples available | Custom plug options | Fast quotation
Available Options
Product Highlights
Designed to support standard applications and project-based requirements.
Technical Specifications
| Model No. | Output Voltage | Min Load | Max Load | Output Current | Max Power | Load Regulation | Line Regulation | Ripple & Noise | AC Plug Type | DC Connector | Remark |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MYX-0502000 | 5V | 0A | 2A | 2A | 10W | ±5% | ±1% | 200mV | US / EU / UK / AU | 5.5×2.1mm / Custom | Typical consumer electronics |
| MYX-0901300 | 9V | 0A | 1.3A | 1.3A | 11.7W | ±5% | ±1% | 200mV | US / EU / UK / AU | 5.5×2.1mm / Custom | Router / small devices |
| MYX-1201000 | 12V | 0A | 1A | 1A | 12W | ±5% | ±1% | 200mV | US / EU / UK / AU | 5.5×2.1mm / 5.5×2.5mm / Custom | Standard 12V option |
| MYX-2400500 | 24V | 0A | 0.5A | 0.5A | 12W | ±5% | ±1% | 200mV | US / EU / UK / AU | 5.5×2.1mm / Custom | For industrial small devices |
Technical Details
Electrical Specifications
Universal 100-240VAC input Short circuit / over voltage / over current protection Compact wall-mounted housing Multiple AC plug types available Custom DC plug and label support
Mechanical Specifications
Compact wall-mounted enclosure Available for multiple AC plug standards Cable and DC connector can be customized
Features
Universal 100-240VAC input Short circuit / over voltage / over current protection Compact wall-mounted housing Multiple AC plug types available Custom DC plug and label support
Model Coding
MYX-XXXYYYYZ XXX = Output voltage code YYYY = Output current code Z = AC plug type
Ordering & Delivery
Lead Time
Sample: 3-7 days / Mass production: 2-4 weeks
Packing Information
Standard export carton packaging available. Custom label and packaging supported.
Delivery Information
Samples by express. Bulk orders by air or sea depending on project requirements.
